High Torque NEMA 23 Stepper Motor For CNC Machine 1.0N.M 2.5A

High Torque NEMA 23 Stepper Motor For CNC Machine 1.0N.M 2.5A

Nama merek:	Casun
Nomor Model:	57SHD4408-21BH
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROHS,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

1.0N.m

Saat ini:

2.5a

Panjang motor:

54mm

Batang:

Penggilingan Poros Datar Panjang 21mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

High Torque NEMA 23 Stepper Motor

2.5A NEMA 23 Stepper Motor

Deskripsi Produk

STEPPER MOTOR NEMA 23 FOR CNC MACHINE 1.0N.M 2.5A

The NEMA 23 stepper motor can provide higher torque than the NEMA 17, which is very useful for applications that require driving larger loads.

Semiconductor manufacturing equipment, laser cutting and engraving machines

Features:

High torque and high precision
Our products are designed for high torque and precision
With 12 years of experience in China, we have served more than 800 customers
Our engineers will react within 48 hours to offer the optimal solution
Wanted dealers! !

Appearance

High Torque NEMA 23 Stepper Motor For CNC Machine 1.0N.M 2.5A 0

Dimensions

High Torque NEMA 23 Stepper Motor For CNC Machine 1.0N.M 2.5A 1

Motor Specifications

Step Angel	1.8 °
Fram Size	57 mm
Number of Phase	2 Phase
Rated Current	2.5 A
Holding Torque	1.0 N.m
Resistance	1.2 ohm
Inductance	4.1 mH
Rotor Inertia	260 g-cm²
Motor weight	0.6 kg
Number of leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
57SHD4013-21B	0.6N.m	1.8°	41mm	D Shaft-21mm	1.0A
57SHD4415-21B	1.1N.m	1.8°	54mm	D Shaft-21mm	3.0A
57SHD4816-21B	2.0N.m	1.8°	76mm	D Shaft-21mm	3.0A
57SHD4913-21B	2.5N.m	1.8°	83mm	D Shaft-21mm	3.0A
57SHD4934-20B	3.0N.m	1.8°	100mm	D Shaft-20mm	3.0A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.

Tag:

2 Phase Bipolar Stepper Motor

Nema 6 Bipolar Stepper Motor

High Torque NEMA 23 Stepper Motor
