Milling Flat Shaft 2 Phase Stepping Motor NEMA 23 For Packaging Equipment

Milling Flat Shaft 2 Phase Stepping Motor NEMA 23 For Packaging Equipment

Nama merek:	Casun
Nomor Model:	57SHD0801-20BH
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROHS,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

1750mN.m

Saat ini:

0,8A

Panjang motor:

76mm

Batang:

Penggilingan Poros datar Panjang 20mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

Flat Shaft 2 Phase Stepping Motor

Packaging Equipment 2 Phase Stepping Motor

Deskripsi Produk

2 Phase Stepping Motor NEMA 23 With CE ROHS ISO For Packaging Equipment

The NEMA23 stepper motor adopts a step-by-step motion method, which can achieve higher speeds.

Advantages such as high precision, high torque, high speed, easy control, and fast dynamic response.

Features:

High torque and high precision
For high-tech industry and electronic industry equipment
Dealers are actively sought after!
In search of partners!
A ten-year warranty for assured purchases

Appearance

Milling Flat Shaft 2 Phase Stepping Motor NEMA 23 For Packaging Equipment 0

Dimensions

Milling Flat Shaft 2 Phase Stepping Motor NEMA 23 For Packaging Equipment 1

Motor Specifications

Step Angel	1.8 °
Fram Size	57 mm
Number of Phase	2 Phase
Rated Current	0.8 A
Holding Torque	1750 mN.m
Resistance	12 ohm
Inductance	48 mH
Rotor Inertia	460 g-cm²
Motor weight	1 kg
Number of leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
57SHD4013-21B	0.6N.m	1.8°	41mm	D Shaft-21mm	1.0A
57SHD4415-21B	1.1N.m	1.8°	54mm	D Shaft-21mm	3.0A
57SHD4816-21B	2.0N.m	1.8°	76mm	D Shaft-21mm	3.0A
57SHD4913-21B	2.5N.m	1.8°	83mm	D Shaft-21mm	3.0A
57SHD4934-20B	3.0N.m	1.8°	100mm	D Shaft-20mm	3.0A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
