Nema 34 Closed Loop Stepper Motor 8.5Nm 6.0A With CE For Industrial Automation Equipment

Nema 34 Closed Loop Stepper Motor 8.5Nm 6.0A With CE For Industrial Automation Equipment

Nama merek:	Casun
Nomor Model:	86SHD4317-37QH
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROHS,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

8,5Nm

Saat ini:

6.0A

Panjang motor:

112mm

Batang:

Poros Alur Pasak Panjang 20mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

Nema 34 Closed Loop Stepper Motor

8.5Nm Closed Loop Stepper Motor

Deskripsi Produk

Nema 34 Closed Loop Stepper Motor 8.5Nm 6.0A With CE For Industrial Automation Equipment

The closed-loop control system can counteract external interference and errors by detecting motion status and position information.

Compatible with existing open-loop stepper motor control systems.

Features:

High torque and high precision
Our products offer high torque and precision
Expertise in professional research and development manufacturing
Our engineers will reach out to you within 48 hours to offer the optimal solution
A ten-year warranty for confident purchases

Motor Specifications

Step Angel	1.8 °
Fram Size	86 mm
Number of Phase	2 Phase
Rated Current	6.0 A
Holding Torque	8.5 N.m
Resistance	0.54 ohm
Inductance	5.0 mH
Rotor Inertia	2700 g-cm²
Motor weight	3.8 kg
Number of leads	4
Connection	Bipolar

Appearance

Nema 34 Closed Loop Stepper Motor 8.5Nm 6.0A With CE For Industrial Automation Equipment 0

Dimensions

Nema 34 Closed Loop Stepper Motor 8.5Nm 6.0A With CE For Industrial Automation Equipment 1

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
57SHD4013-21B	0.6N.m	1.8°	41mm	D Shaft-21mm	1.0A
57SHD4415-21B	1.1N.m	1.8°	54mm	D Shaft-21mm	3.0A
57SHD4816-21B	2.0N.m	1.8°	76mm	D Shaft-21mm	3.0A
57SHD4913-21B	2.5N.m	1.8°	83mm	D Shaft-21mm	3.0A
57SHD4934-20B	3.0N.m	1.8°	100mm	D Shaft-20mm	3.0A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
