1.8 Degree NEMA 17 Stepper Motor DC 24V High Precision 4 Leads

1.8 Degree NEMA 17 Stepper Motor DC 24V High Precision 4 Leads

Nama merek:	Casun
Nomor Model:	42SHD4077-24BH
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROHS,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

192mN.m

Saat ini:

0,24A

Panjang motor:

34 MM

Batang:

Penggilingan Poros Datar Panjang 24mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

1.8 Degree NEMA 17 Stepper Motor

High Precision NEMA 17 Stepper Motor

Deskripsi Produk

1.8 Degree NEMA17 Stepper Motor DC 24V High Precision 4 Leads

The 42mm stepper motors have advantages in applications with high cost and complexity requirements.

The control of stepper motors is relatively simple, usually only requiring a pulse signal to control the number of rotation steps and speed.

Features:

Bipolar or unipolar versions available
Supply "multiple international certifications" for high-tech and electronic industry equipment
Focused on drivetrain solutions
Professional research and development manufacturing
Tailored service options

Appearance

1.8 Degree NEMA 17 Stepper Motor DC 24V High Precision 4 Leads 0

Dimensions

1.8 Degree NEMA 17 Stepper Motor DC 24V High Precision 4 Leads 1

4Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	0.24 A
Holding Torque	192 mN.m
Resistance	50 ohm
Inductance	55 mH
Rotor Inertia	38 g-cm²
Motor weight	0.2 kg
Number of leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
