0.55A 0.3N.M NEMA 17 Hybrid Stepping Motor 34mm Body For CNC Machine Tool

0.55A 0.3N.M NEMA 17 Hybrid Stepping Motor 34mm Body For CNC Machine Tool

Nama merek:	Casun
Nomor Model:	42SHD4002-24BH
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROHS,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

300mN.m

Saat ini:

0,55A

Panjang motor:

34 MM

Batang:

Penggilingan Poros Datar Panjang 24mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

0.55A Hybrid Stepping Motor

34mm Body Hybrid Stepping Motor

Deskripsi Produk

Stepping Motor 34mm Body 0.55A 0.3N.M NEMA 17 For CNC Machine Tool

The 42mm stepper motor does not require external sensors for position feedback during control, simplifying system design and reducing costs.

Accurate position control without feedback system.

Features:

Bipolar or unipolar versions available
Tailored service options
Available in single or double shaft versions
Offer "numerous international certifications" for high-tech and electronic industry equipment
Having operated in China for 12 years, we have catered to over 800 customers

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	0.55 A
Holding Torque	300 mN.m
Resistance	22 ohm
Inductance	28 mH
Rotor Inertia	38 g-cm²
Motor weight	0.2 kg
Number of leads	4
Connection	Bipolar

Appearance

0.55A 0.3N.M NEMA 17 Hybrid Stepping Motor 34mm Body For CNC Machine Tool 0

Dimensions

0.55A 0.3N.M NEMA 17 Hybrid Stepping Motor 34mm Body For CNC Machine Tool 1

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
