F57SHD4228 2 Phase NEMA 23 Hybrid Stepper Motor Waterproof 51mm Body 1.16N.M For Smart Devices

F57SHD4228 2 Phase NEMA 23 Hybrid Stepper Motor Waterproof 51mm Body 1.16N.M For Smart Devices

Nama merek:	Casun
Nomor Model:	F57SHD4228-21H
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROHS,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

1100mN.m

Saat ini:

2.5a

Panjang motor:

51mm

Batang:

Poros Bulat Panjang 21mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

Hybrid Stepper Motor Waterproof

F57SHD4228 Hybrid Stepper Motor

Deskripsi Produk

【F57SHD4228】2 Phase NEMA 23 Hybrid Waterproof Stepper Motor 51mm Body 1.16N.m for Smart Devices

The 57mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.

Features:

High torque and high precision
For high-tech industry and electronic industry equipment
Our engineers will be in touch within 48 hours to provide the best solution
Professional research and development manufacturing
High torque and high precision

Appearance

F57SHD4228 2 Phase NEMA 23 Hybrid Stepper Motor Waterproof 51mm Body 1.16N.M For Smart Devices 0

Dimensions

F57SHD4228 2 Phase NEMA 23 Hybrid Stepper Motor Waterproof 51mm Body 1.16N.M For Smart Devices 1

Motor Specifications

Step Angel	1.8 °
Fram Size	57 mm
Number of Phase	2 Phase
Rated Current	2.5 A
Holding Torque	1100 mN.m
Resistance	1.15 ohm
Inductance	3.3 mH
Rotor Inertia	220 g-cm²
Motor weight	0.62 kg
Number of leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
57SHD4013-21B	0.6N.m	1.8°	41mm	D Shaft-21mm	1.0A
57SHD4415-21B	1.1N.m	1.8°	54mm	D Shaft-21mm	3.0A
57SHD4816-21B	2.0N.m	1.8°	76mm	D Shaft-21mm	3.0A
57SHD4913-21B	2.5N.m	1.8°	83mm	D Shaft-21mm	3.0A
57SHD4934-20B	3.0N.m	1.8°	100mm	D Shaft-20mm	3.0A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
