Waterproof 57SHD4228 NEMA 23 Hybrid Stepper Motor 2 Phase 51mm Body 1.16N.M For Smart Devices

Waterproof 57SHD4228 NEMA 23 Hybrid Stepper Motor 2 Phase 51mm Body 1.16N.M For Smart Devices

Nama merek:	Casun
Nomor Model:	F57SHD4228-21H
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROHS,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

1100mN.m

Saat ini:

2.5a

Panjang motor:

51mm

Batang:

Poros Bulat Panjang 21mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

57SHD4228 Hybrid Stepper Motor

Waterproof 51mm Hybrid Stepper Motor

Deskripsi Produk

The NEMA 23 waterproof stepper motor has been specially designed and sealed.

It can adapt to harsh environmental conditions and therefore has high reliability and stability.

Features:

High torque and high precision
For high-tech industry and electronic industry equipment
Professional research and development manufacturing
We offer custom services and accept contract manufacturing
Having operated in China for 12 years, we have catered to over 800 customers

Motor Specifications

Step Angel	1.8 °
Fram Size	57 mm
Number of Phase	2 Phase
Rated Current	2.5 A
Holding Torque	1100 mN.m
Resistance	1.15 ohm
Inductance	3.3 mH
Rotor Inertia	220 g-cm²
Motor weight	0.62 kg
Number of leads	4
Connection	Bipolar

Appearance

Waterproof 57SHD4228 NEMA 23 Hybrid Stepper Motor 2 Phase 51mm Body 1.16N.M For Smart Devices 0

Dimensions

Waterproof 57SHD4228 NEMA 23 Hybrid Stepper Motor 2 Phase 51mm Body 1.16N.M For Smart Devices 1

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
57SHD4013-21B	0.6N.m	1.8°	41mm	D Shaft-21mm	1.0A
57SHD4415-21B	1.1N.m	1.8°	54mm	D Shaft-21mm	3.0A
57SHD4816-21B	2.0N.m	1.8°	76mm	D Shaft-21mm	3.0A
57SHD4913-21B	2.5N.m	1.8°	83mm	D Shaft-21mm	3.0A
57SHD4934-20B	3.0N.m	1.8°	100mm	D Shaft-20mm	3.0A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
