rincian produk

Rumah Produk

Nema17 Low price stepping motor voltage 3.75V 1.5Amp 500mN.m 0.24kg stepping motor for Sewing machine

Nema17 Low price stepping motor voltage 3.75V 1.5Amp 500mN.m 0.24kg stepping motor for Sewing machine

Nama merek:	Casun
Nomor Model:	42SHD4217-24B
MOQ:	1 buah
Harga:	$5.0-$6.2
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROSH,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

500mN.m

Saat ini:

1.5a

Panjang motor:

1000

Batang:

Poros Bulat Panjang 20mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

500mN.m Nema17 Stepping Motor

1.5Amp Nema17 Stepping Motor

3.75V Nema17 Stepping Motor

Deskripsi Produk

20x20x33mm 0.6A Casun Stepper Motor Nema 8 Mini Stepper Motor For Medical beauty equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	42mm
Number of Phase	2 Phase
Rated Current	1.5A
Holding Torque	500mN.m
Resistance	2.2ohm
Inductance	5mH
Rotor Inertia	57 g-cm²
Motor weight	0.24kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
