Nema17 4A Pulse 2 Phase Stepper Motor Driver For CNC Engraving Machine

Nema17 4A Pulse 2 Phase Stepper Motor Driver For CNC Engraving Machine

Nama merek:	Casun
Nomor Model:	TB6600
MOQ:	1 buah
Harga:	$3-$6
Ketentuan Pembayaran:	L/C, D/A, D/P, T/T
Kemampuan Pasokan:	5000pcs+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Aplikasi:

Motor stepper dua fase Nema23/24/34/42

Rentang Saat Ini:

1,5-4,5A

Fase keluaran:

2 Fase

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

38X29X18cm

Menyoroti:

4A 2 Phase Stepper Motor Driver

Nema17 2 Phase Stepper Motor Driver

Casun CNC Stepper Motor Driver

Deskripsi Produk

TB6600 Stepper Motor Driver Nema17 4A pulse 9-42v dc pwer supply controller Stepping Motor For CNC Engraving Machine

Product Name	TB6600
Size	965728mm
Supply voltage	9-24V
Color	Black

Specifications:

This drive is an upgraded version of the TB6600, the breakdown of heightening to 32 segments, for high segmentation purposes. Applicable stepper motor: 42,57,86 type of 2-phase 4-phase (4-wire 6 wire line 8)

Micro stp	Pulse/rev	S1	S2	S3
NC	NC	ON	ON	ON
1	200	ON	ON	OFF
2/A	400	ON	OFF	ON
2/B	400	OFF	ON	ON
4	800	ON	OFF	OFF
8	1600	OFF	ON	OFF
16	3200	OFF	OFF	ON
32	6400	OFF	OFF	OFF

Current(A)	PK Current	S4	S5	S6
0.5	0.7	ON	ON	ON
1.0	1.2	ON	OFF	ON
1.5	1.7	ON	ON	OFF
2.0	2.2	ON	OFF	OFF
2.5	2.7	OFF	ON	ON
2.8	2.9	OFF	OFF	ON
3.0	3.2	OFF	ON	OFF
3.5	4.0	OFF	OFF	OFF

Features:

Suitable for stepping motor: 42-phase, 47-phase and 86-phase (4-wire, 6-wire and 8-wire)

1, 9V-42V DC power supply;

2, H-bridge bipolar constant-phase flow-driven;

3, the maximum output current of 4.0A eight optional;

4, up to 32 segments of six kinds of sub-modes available;

5, the input signal is high-speed optical isolation.

6, standard common anode single pulse interface;

7, offline hold function;

8, semi-enclosed chassis can accommodate more demanding environment;

9, provide energy semiautomatic current lock function;

10, built-in thermal protection and overcurrent protection.
