CNC Robot 42mm NEMA 17 Stepper Motor 0.8A 700mN.M Casun Stepper Motor

CNC Robot 42mm NEMA 17 Stepper Motor 0.8A 700mN.M Casun Stepper Motor

Nama merek:	Casun
Nomor Model:	42SHD0811-25B
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROSH,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

700mN.m

Saat ini:

0,8A

Panjang motor:

60mm

Batang:

Penggilingan Poros Datar Panjang 25mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

CNC Robot 42mm NEMA 17

42mm NEMA 17 Stepper Motor

700mN.M Casun Stepper Motor

Deskripsi Produk

The 42mm Hybrid Stepper Motor is driven by a single stepper pulse, so its motion is very reliable.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Features:

High torque and high precision
For high-tech industry and electronic industry equipment
Available in single or double shaft versions
Established in China for 12 years and has served more than 800 customers.
We are open to contract manufacturing arrangements

Appearance

CNC Robot 42mm NEMA 17 Stepper Motor 0.8A 700mN.M Casun Stepper Motor 0

Dimensions

CNC Robot 42mm NEMA 17 Stepper Motor 0.8A 700mN.M Casun Stepper Motor 1

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	0.8 A
Holding Torque	700 mN.m
Resistance	20 ohm
Inductance	42.5 mH
Rotor Inertia	102 g-cm²
Motor weight	0.45 kg
Number of leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
