【42SHD0441】42x42x48mm 1.8 Degree 2 Phase 1.2A for 3D Printer Hybrid Nema 17 Stepper Motor

【42SHD0441】42x42x48mm 1.8 Degree 2 Phase 1.2A for 3D Printer Hybrid Nema 17 Stepper Motor

Nama merek:	Casun
Nomor Model:	42SHD0441-24B1
MOQ:	1 buah
Harga:	$3.14-$5
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROHS,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

420mN.m

Saat ini:

1.2A

Panjang motor:

48mm

Batang:

Penggilingan Poros Datar Panjang 24mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

1.8 Degree Nema 17 Stepper Motor

1.2A Nema 17 Stepper Motor

3D Printer Nema 17 Stepper Motor

Deskripsi Produk

The NEMA 17 motor can provide higher torque, enabling it to drive larger loads while maintaining relatively high speeds and smooth motion.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Features:

Bipolar or unipolar versions available
For high-tech industry and electronic industry equipment
Both contract manufacturing and specialised services are available from us. Needed dealers!
Professional drivetrain solution specialist
Buy with assurance thanks to the ten-year warranty

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	1.2 A
Holding Torque	420 mN.m
Resistance	3.2 ohm
Inductance	6.0 mH
Rotor Inertia	72 g-cm²
Motor weight	0.38 kg
Number of leads	4
Connection	Bipolar

Appearance

【42SHD0441】42x42x48mm 1.8 Degree 2 Phase 1.2A for 3D Printer Hybrid Nema 17 Stepper Motor 0

Dimensions

【42SHD0441】42x42x48mm 1.8 Degree 2 Phase 1.2A for 3D Printer Hybrid Nema 17 Stepper Motor 1

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
