Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

Nama merek:	Casun
Nomor Model:	20SHD0501-20
MOQ:	1 buah
Harga:	$5.94-$8.6
Ketentuan Pembayaran:	D/A, T/T, L/C, D/P
Kemampuan Pasokan:	40000+Buah+Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

CE,ROSH,ISO

Langkah Malaikat:

1,8°

Memegang Torsi:

20mN.m

Saat ini:

0,6A

Panjang motor:

33mm

Batang:

Poros Bulat Panjang 10mm

Disesuaikan:

Motor dapat dirancang & diproduksi dengan permintaan khusus.

Kemasan rincian:

Karton: 36x29x14cm

Menyoroti:

0.6A Casun Stepper Motor

Mini 20mNm NEMA 8 Stepper Motor

Casun NEMA 8 Stepper Motor

Deskripsi Produk

20x20x33mm 0.6A Casun Stepper Motor Nema 8 Mini Stepper Motor For Medical beauty equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	20 mm
Number of Phase	2 Phase
Rated Current	0.6 A
Holding Torque	20 mN.m
Resistance	5.8 ohm
Inductance	1.5 mH
Rotor Inertia	2.5 g-cm²
Motor weight	0.07 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
